1. Procedure
2. Notes
1.
N-Benzyl aniline (99%) was purchased from Aldrich Chemical Company, Inc.
2.
Dichloromethane (HPLC grade) was purchased from Fisher Scientific Company and used as received.
3.
tert-Butyl malonate (97%) was purchased from Alfa Aesar.
The supplied material contained 5-10%
tert-butyl ethyl malonate as an impurity, but was used as received.
4.
2-Chloro-1-methylpyridinium iodide (Mukaiyama's reagent; 97%) was purchased from Aldrich Chemical Company, Inc.
5.
Triethylamine was purchased from Aldrich Chemical Company, Inc.
6.
TLC analysis was carried out using silica gel plates
(Note 28) with petroleum ether-Et
2O (1:1) as eluent and visualisation with UV (254 nm) and
p-anisaldehyde.
N-Benzyl aniline
1 has R
f = 0.77 (white) and the product
3 has R
f = 0.42 (purple).
7.
The crude material was purified by column chromatography.
A 60-mm diameter column was wet-packed with a silica gel slurry made from petroleum ether/Et
2O (3:1) (180 g)
(Note 30) to give a 160-mm column depth.
Sand (1 cm) was layered onto the silica and the crude oil suspended in the eluent (25 mL) and poured onto the sand.
Washings are also loaded with further portions of the eluent (2 × 25 mL) and 400 mL of eluent was collected.
Fractions (16 × 150 mm test tubes) are collected from 600 mL of petroleum ether/Et
2O (3:1) and 1.5 L of petroleum ether/Et
2O (1:1) to give 55 fractions.
The product was identified by thin layer chromatography (petroleum ether/Et
2O (1:1); R
f = 0.42) and fractions 15-53 are collected and concentrated by rotary evaporation (35 °C water-bath, 15 to 10 mmHg).
The material was then dried overnight under high vacuum (0.08 mmHg) with an oval stir-bar to yield the product.
8.
The checkers report an 88% yield when the reaction was performed at half-scale.
Compound
3 exhibits the following physical and spectroscopic properties:
1H NMR
pdf(400 MHz, CDCl
3) δ: 1.42 (s, 9 H), 3.14 (s, 2 H), 4.91 (s, 2 H), 7.01-7.03 (m, 2 H), 7.23-7.26 (m, 5 H), 7.29-7.31 (m, 3 H);
13C NMR
pdf(100 MHz, CDCl
3) δ: 28.1, 43.1, 53.1, 81.6, 127.6, 128.5, 128.9, 129.8, 137.3, 142.1, 166.4, 167.0; IR (neat): 3063, 2978, 1731, 1660, 1495, 1392, 1367, 1326, 1142, 697 cm
−1; HRMS (ESI)
m/z 326.1749 [326.1751 calcd for C
20H
24NO
3 (M+H)].
Anal.
Calcd for: C, 73.82, H, 7.12, N, 4.30.
Found: C, 73.59, H, 7.13, N, 4.41.
9.
Tetrahydrofuran (HPLC grade) was purchased from Fisher and purified using a Innovative Technology Inc.
Pure Solv™ solvent purification system.
10.
Potassium
tert-butoxide was purchased from Aldrich Chemical Company, Inc.
11.
Methyl iodide was purchased from Aldrich Chemical Company, Inc.
12.
TLC analysis was carried out using silica gel plates
(Note 28) with petroleum ether-Et
2O (1:1) as eluent and visualisation with UV (254 nm) and
p-anisaldehyde.
tert-Butyl 3-(benzyl(phenyl)amino)-3-oxopropanoate
3 has R
f = 0.38 (purple) and the product
4 has R
f = 0.48 (blue).
13.
Diethyl ether (Lab reagent grade) was supplied by Fisher Scientific.
14.
A 60-mm diameter column was wet-packed with silica gel (220 g)
(Note 30) to give a 140 mm column depth.
Sand (1 cm) was layered onto the silica and the crude oil suspended in the eluent (25 mL) and poured onto the sand.
Washings are also loaded in a further portion of eluent (25 mL).
Fractions (45 mL) are collected from 4 L of petroleum ether/Et
2O (7:3).
The 49 fractions were analyzed by TLC (petroleum ether/Et
2O :7:3) and the product (R
f = 0.27) identified in fractions 11-35, which were collected and concentrated by rotary evaporation (32 °C water-bath, 15 to 10 mmHg).
The residual material was dried overnight under high vacuum (0.1 mbar) with an oval stir bar to yield the product
4.
15.
The checkers report a 91% yield when the reaction was performed at half-scale.
Compound
4 exhibits the following physical and spectroscopic properties:
1H NMR
pdf(400 MHz, CDCl
3) δ: 1.28 (d,
J = 7 Hz, 3 H), 1.41 (s, 9 H), 3.27 (q,
J = 7.2, 1 H), 4.57 (d,
J = 14.4 Hz, 1 H), 5.22 (d,
J = 14.4 Hz, 1 H), 7.01-7.04 (m, 2 H), 7.22-7.27 (m, 5 H), 7.30-7.34 (m, 3 H);
13C NMR
pdf(100 MHz, CDCl
3) δ: 14.2, 28.1, 44.6, 53.2, 81.3, 127.6, 128.5, 128.7, 128.9, 129.8, 137.6, 142.2, 169.9, 170.5; IR (neat): 3063, 2978, 2935, 1738, 1656, 1595, 1495, 1454, 1393, 1367, 1325, 1245, 1147, 848, 735, 697 cm
−1; HRMS (ESI)
m/z 340.1906 [340.1907 calcd for C
21H
26NO
3 (M+H)].
Anal.
Calcd for: C, 74.31; H, 7.42, N, 4.13.
Found: C, 73.49; H, 7.29, N, 4.15.
16.
N,N-Dimethylformamide (anhydrous, 99.8%) was purchased from Sigma-Aldrich and used as received.
Submitters purchased
N,N-dimethylformamide from Fisher Scientific and purified using a Innovative Technology Inc.
Pure Solv™ solvent purification system.
17.
Copper(II) acetate monohydrate was purchased from Aldrich Chemical Company, Inc.
18.
TLC analysis was carried out using silica gel plates
(Note 28) with petroleum ether-Et
2O (1:1) as eluent and visualisation with UV (254 nm) and
p-anisaldehyde.
tert-Butyl 3-(benzyl(phenyl)amino)-2-methyl-3-oxopropanoate
4 has R
f = 0.50 (blue) and the product
5 has R
f = 0.68 (purple).
19.
A 60-mm diameter column was wet-packed with silica gel (120 g)
(Note 30) to give a 110-mm column depth.
Sand (1 cm) was layered onto the silica and the crude oil suspended in dichloromethane (10 mL) and poured onto the sand.
Washings were also loaded in a further portion of dichloromethane (5 mL).
Fractions (16 × 150 mm tubes) were collected from 1.5 L of petroleum ether/Et
2O (4:1).
The 90 fractions were evaluated by thin layer chromatography (petroleum ether/Et
2O; 4:1) product R
f = 0.26) and fractions 37-81 were collected and concentrated (Rotary evaporation (32 °C water-bath, 15 to 10 mmHg)) to yield the product.
20.
The colorless solid was suspended in hexane (50 mL) and filtered, collecting the solid on a sinter (60 mL, porosity 3) and washing with three additional portions of 100 mL portions of hexane
(Note 27).
The colorless solid obtained was transferred to a 50-mL round-bottomed flask and dried overnight under high vacuum (0.08 mmHg).
21.
The checkers report a 50% yield when the reaction was performed at half-scale.
Compound
5 exhibits the following physical and spectroscopic properties: mp 106-107 °C;
1H NMR
pdf(400 MHz, CDCl
3) δ: 1.36 (s, 9 H), 4.66 (d,
J = 16 Hz, 1 H), 5.22 (d,
J = 16 Hz, 1 H), 6.68 (d,
J = 7.6 Hz, 1 H), 7.02 (ddd,
J = 1.2, 7.6, 7.6 Hz, 1 H), 7.17 (ddd,
J = 1.2, 7.6, 7.6 Hz), 7.23-7.33 (m, 6 H);
13C NMR
pdf(100 MHz, CDCl
3) δ: 20.1, 28.0, 43.9, 56.1, 82.6, 109.6, 122.8, 123.0, 127.3, 127.8, 128.9, 130.9, 135.9, 142.9, 168.9, 175.8; IR (film): 3061, 2979, 2932, 1732, 1713, 1609, 1488, 1466, 1368, 1252, 1152, 1115, 1108, 748, 697 cm
−1; HRMS (ESI)
m/z 338.1749 [338.1751 calcd for C
21H
24NO
3 (M+H)].
Anal.
Calcd for: C, 74.75, H, 6.87, N, 4.15.
Found: C, 74.56, H, 6.94, N, 4.19.
22.
Trifluoroacetic acid, 98% was purchased from Aldrich Chemical Company Inc.
23.
TLC analysis was carried out using silica gel plates
(Note 28) with petroleum ether-Et
2O (1:1) as eluent and visualisation with UV (254 nm) and
p-anisaldehyde.
tert-Butyl 1-benzyl-3-methyl-2-oxoindoline-3-carboxylate
5 has R
f = 0.68 (purple) and the product
6 has R
f = 0.46 (pink).
24.
Ethanol (analytical reagent grade) was purchased from Fisher Scientific and used as received.
25.
The colorless solid was dissolved in the minimum amount of boiling ethanol (ca.
15 mL) and allowed to cool to room temperature.
The crystals were broken up with a spatula and collected
via filtration in a sinter (60 mL, porosity 3) washing with three 50 mL portions of hexane
(Note 27).
The crystals were transferred to a 50-mL round-bottomed flask and dried overnight under high vacuum (0.08 mmHg).
26.
The checkers report an 81% yield when the reaction was performed at half-scale.
Compound
6 exhibits the following physical and spectroscopic properties: mp 119-120 °C;
1H NMR
pdf(400 MHz, CDCl
3) δ: 1.54 (d,
J = 8 Hz, 3 H), 3.54 (q,
J = 7.6 Hz, 1 H), 4.92 (s, 2 H), 6.72 (d,
J = 8 Hz, 1 H), 7.02 (ddd,
J = 1.2, 7.6, 7.6 Hz), 7.16 (dt,
J = 1.2, 2, 8 Hz, 1 H), 7.24-7.34 (m, 6 H);
13C NMR
pdf(100 MHz, CDCl
3) δ: 15.9, 40.8, 43.9, 109.2, 122.7, 123.8, 127.5, 127.8, 128.0, 129.0, 130.9, 136.2, 143.3, 179.0 ppm; IR (film): 3057, 3031, 2930, 1704, 1613, 1487, 1466, 1454, 1348, 1202, 1169, 972, 749, 687 cm
−1; HRMS (ESI)
m/z 238.1224 [238.1226 calcd.
for C
16H
16NO (M+H)].
Anal.
Calcd.
for: C, 80.98; H, 6.37, N, 5.90.
Found: C, 80.70; H, 6.24, N, 5.91.
The physical and spectroscopic data matches those previously reported.
2
27.
n-Hexane (HPLC grade) was purchased from Fisher Scientific and used as received.
28.
TLC plates were supplied by Merck, aluminium backed silica gel 60 (F
254).
29.
Petroleum ether (lab reagent grade) supplied by Fisher Scientific.
Diethyl ether (anhydrous) was supplied by Fisher Scientific.
30.
Silica Gel (60) was purchased from Sorbent Technologies.
Submitters purchased silica gel (60) from Fluka.
The procedures in this article are intended for use only by persons with prior training in experimental organic chemistry. All hazardous materials should be handled using the standard procedures for work with chemicals described in references such as "Prudent Practices in the Laboratory" (The National Academies Press, Washington, D.C., 2011 www.nap.edu). All chemical waste should be disposed of in accordance with local regulations. For general guidelines for the management of chemical waste, see Chapter 8 of Prudent Practices.
These procedures must be conducted at one's own risk. Organic Syntheses, Inc., its Editors, and its Board of Directors do not warrant or guarantee the safety of individuals using these procedures and hereby disclaim any liability for any injuries or damages claimed to have resulted from or related in any way to the procedures herein.
3. Discussion
